Cruise informatiom

R/V Thompson | ROV Jason and AUV Sentry | Seattle-Seattle, August 14-29

First Jason Dive

Tuesday, August 18
By Bill Chadwick

Axial Seamount 2015 Expedition video highlights from ROV Jason dive J2-820, including collection of samples from the 2015 lava flows on the north rift zone, fluids from hydrothermal vents (including some where vent animals have already colonized), and microbial mats on the new lavas. Video by Jesse Crowell in association with Saskia Madlener at 77th Parallel Productions. Music by James Andrew Menking

Map of the 2015 lava flows on Axial’s north rift zone, showing our Jason dive track (in blue).
Our first ROV Jason dive explored some of the new lava flows on Axial’s North Rift Zone. There are two large, thick new flows located 8-16 km north of the summit caldera.  Our first Jason dive started near the southern end of those new flows and traversed northward for about 2 km (right).  Here’s what we found.

Thick fluffy microbial mat has grown on top of the 2015 lava flows while they are cooling.
Almost everywhere the new lava flows are covered with what we call “eruption mat”.  This mat looks like a yellow to orange fuzzy coating on the surface of the new lavas that forms by microbes growing on the lavas as they cool in the weeks and months after the eruption (left).  We have also seen this after previous eruptions at Axial Seamount.  The microbial mat varies in thickness and color from place to place, and even covers some of the older lavas around the new flows.
Thin edge of the 2015 lava flows where they are dark and glassy and not covered with microbial mat.
This can make it a little confusing to distinguish the new and old lavas in some places, but where there is little or no mat the new lavas are black and glassy (right).  We sampled the new lavas in order to determine their chemical composition to see how the 2015 eruption compares to previous ones, and for high-resolution age dating which will help piece together the duration of the eruption and a sequence of events (below).
Jason takes a sample of the 2015 lava.
Edge of the eruptive fissure where 2015 lava is seen draining back into the crack.
Fluid sheet flows with a short lava pillar near the 2015 eruptive fissure.
As Jason traversed from south to north we were able to follow the eruptive fissure (where the lava had come out of the ground) in many places (left-middle).  Several of the new lava flows were thin and fluid (Fig6), and even where the lava flows are thicker, they have drained out collapse features, indicating that the flow lobes had a molten interior when they were emplaced (left-bottom).

We found many new hydrothermal vents on the new flows, areas where warm shimmering water (up to 20°C) was coming out of the seafloor, undoubtedly heated up by the eruption and the slow cooling of the lavas (we know there were few vents on the north rift zone before the eruption).  We saw a lot of microbial flocculant floating in the water, suggesting that “snowblower vents” exist on the new flows, but we just did not run across them.  One exciting surprise was that we found several vents that had already been colonized by vent animals –tubeworms (Ridgeia piscesae) and Pandorae worms (Paralvinella pandorae) (below-top).  The tubeworms are small (less than 5 cm long), having colonized and grown only in the last 4 months, but interestingly the Pandorae worms are unusually large, perhaps because of the lack of competition in these brand-new vents right after an eruption (according to our colleague Verena Tunnicliffe at University of Victoria).
Tubeworms and Pandorae worms have already colonized hydrothermal vents on the new lava flows.

An octopus strikes a defensive pose on the 2015 lava flows.
We also encountered two deep-sea octopi (Graneldone sp.), one of which appeared to be trying to make itself as large and scary as possible to intimidate Jason into leaving it alone (below-bottom).

Our first dive with Jason was very successful, but unfortunately it had to be cut short due to rising winds and seas.  The forecast is for the weather to get worse before it gets better, so we will likely not be able to dive again for a few days and we’ll be conducting other operations in the meantime.
